Aluminium Casement Window - Premium (ACW 81 Ext Glazed Fixed)
Material

Aluminium

Glass Specification

28mm

Glazed

Externally Glazed Fixed Lights and Internally Glazed Casements

Lowest Glass Value

1.0 m²K

Lowest Overall Frame Value

1.5 m²K

Frame depth

73mm

Outer frame height

43mm or 55mm

Sash designs

Square Only

Standard solid colours

Matt Grey 7016, White Satin 9016 or Matt Black 9005

Aluminium Casement Window

Premium (ACW 81 Ext Glazed Fixed)

Strong, secure, superior. This effective and high performance solution offers clean lines and advanced functionality. Available with a range of customisable options, the premium range aluminium windows are the perfect choice for both traditional and contemporary residential designs. To configure your choice of window, complete the configurator and add to basket for your final price. For help read the FAQ’s or contact us.

Strong, secure, superior. This effective and high performance solution offers clean lines and advanced functionality. Available with a range of customisable options, the premium range aluminium windows are the perfect choice for both traditional and contemporary residential designs. To configure your choice of window, complete the configurator and add to basket for your final price. For help read the FAQ’s or contact us.

Choose Options

Measurements

Width (300mm - 3500mm)
Width

Measuring doors & windows is simple but please follow our easy instructions:

  • For bifold & sliding doors to work as smoothly as designed, it is imperative that the outer frame is fitted level and square. To ensure this, you must measure the brickwork aperture as shown below.

  • Three measurements of width and height should be taken and the squareness of the aperture determined by, for example, taking diagonal measurements (see image below). The smallest measurement of width and of height minus a fitting tolerance (usually 10mm) is used to determine manufacturing sizes.

Please also take into account the height of the door’s threshold, that you step over. This is critical for the following reasons:

  • On open-out folding doors with a standard threshold, it allows the possibility of aligning your internal floor with the top of the threshold, to reduce the step over height.

  • On open-out folding doors with an aluminium low threshold, it ensures a level transition from outside to inside, or between internal rooms.

  • On open-in doors it ensures that the opening door sashes do not foul your internal floor.

mm
Height (300mm - 2500mm)
Height

Measuring doors & windows is simple but please follow our easy instructions:

  • For bifold & sliding doors to work as smoothly as designed, it is imperative that the outer frame is fitted level and square. To ensure this, you must measure the brickwork aperture as shown below.

  • Three measurements of width and height should be taken and the squareness of the aperture determined by, for example, taking diagonal measurements (see image below). The smallest measurement of width and of height minus a fitting tolerance (usually 10mm) is used to determine manufacturing sizes.

Please also take into account the height of the door’s threshold, that you step over. This is critical for the following reasons:

  • On open-out folding doors with a standard threshold, it allows the possibility of aligning your internal floor with the top of the threshold, to reduce the step over height.

  • On open-out folding doors with an aluminium low threshold, it ensures a level transition from outside to inside, or between internal rooms.

  • On open-in doors it ensures that the opening door sashes do not foul your internal floor.

mm
Style
Style

The Mullion width (W1 & W2) in the image shown is measured from the side of the frame to the centre of the mullion bar. The industry standard is 600mm. The transom height (H1) is measured from the top of the frame to the centre of the transom bar. The industry standard is 400mm.

Fire Escape Regulations

New Build Property

To conform to building regulations all first floor windows must have a means of fire escape. Bathrooms, toilet and landing windows however are exempt.

This window can be installed on the ground floor without consideration unless it is in a room that does not lead directly into a hallway or does not have a main exit door.

A fire escape window should open without obstruction to at least 0.33 mu² and at least 450 mm high or 450 mm wide. If one of the dimensions is at the 450 mm minimum, then the other dimension will need to be at least 734 mm to achieve 0.33 mu². The bottom of the openable area should be no more than 1100mm above the floor.

Replacement Windows

Current regulations state that you can not downgrade your existing means of escape in the event of a fire. A window with a mullion conforms, subject to the above, and would not downgrade your means of escape.

Style 1
--
Style 2
--
Style 3
--
Style 4
--
Style 5
--
Style 6
--
Style 7
--
Style 8
--
Style 13
--
Style 14
--
Style 15
--
Style 16
--
Style 17
--
Style 18
--
Style 21
--
Style 23
--
Style 24
--
Style 25
--
Style 26
--
Style 27
--
Style 33
--
Style 34
--
Style 35
--
Style 36
--
Style 37
--
Style 38
--
Style 67
--
Style 78
--
Style 88
--
Style 89
--

Product Options

Colour ** When ordering Bespoke RAL or Dual RAL, the total cost of all special colour options must exceed £2500 inc. VAT **
Colour

When ordering Bespoke RAL or Dual RAL, the total cost of all special colour options must exceed £2500 inc. VAT

To view in full size click here

White RAL 9016
+£0.00
Dark Grey RAL 7016
+£0.00
Black RAL 9005
+£0.00
Bespoke RAL
+£35.00
Dual RAL
+£55.00
Frame Type
Slim 43mm Frame
+£0.00
55mm Frame
+£35.00
Cill
No Cill
+£0.00
90mm Cill
+£0.00
150mm Cill
+£0.00
190mm Cill
+£0.00
230mm Cill
+£0.00
Sash
None
+£0.00
Square
+£0.00
Trickle Vent
Trickle Vent

PVC Windows

Trickle vents on PVC windows are fitted to each opening sash unless there are more than two where they will be fitted to the first and last sash. Fixed PVC windows are fitted with a 20mm frame extension at the head of the window and the vent is fitted into the frame. These are a PVC vent in either white, tan or rosewood.

Contemporary Aluminium Windows

33mm slim frame

Trickle vents on these windows are fitted to a 42mm frame extension at the head of the window above the first and last sash or centrally if this is one sash. These are an aluminium trickle vent in either grey, white or black.

47.5mm frame

Trickle vents on these windows are fitted to the frame with a 33mm frame extension at the head of the window above the first and last sash or centrally if this is one sash. These are an aluminium trickle vent in either grey, white or black.

Premium & Designer Windows

43mm slim frame

Trickle vents on these windows are fitted to a 38mm frame extension at the head of the window above the first and last sash or centrally if this is one sash. These are an aluminium trickle vent in either white or black.

55mm frame

Trickle vents on these windows are fitted to the frame with a 20mm frame extension at the head of the window above the first and last sashor centrally if this is one sash. These are an aluminium trickle vent in either white or black

PVC Tilt & Turn Windows

Trickle vents on these windows are fitted to each opening sash. These are a PVC vent in either white, tan or rosewood.

Aluminium Tilt & Turn Windows

Trickle vents on these windows are fitted to the frame. These are an aluminium trickle vent in either white or black.

Yes
+£0.00
No
+£0.00
Handle Colour
None
+£0.00
White
+£0.00
Black
+£0.00
Grey
+£0.00
Chrome
+£0.00
Gold
+£0.00
Satin Silver
+£0.00

Glass

Glass Option
1.6 Overall U Value - 29% Heat Reflective
+£0.00
1.5 Overall U Value - 36% Heat Reflective
+£25.00
1.5 Overall U Value - 47% Heat Reflective
+£45.00
Obscure Glass
None
+£0.00
Satin
+£0.00
Arctic
+£0.00
Autumn
+£0.00
Chantilly
+£0.00
Charcoal Sticks
+£0.00
Contora
+£0.00
Cotswold
+£0.00
Digital
+£0.00
Everglade
+£0.00
Flemish
+£0.00
Florielle
+£0.00
Mayflower
+£0.00
Minster
+£0.00
Oak
+£0.00
Pelerine
+£0.00
Reeded
+£0.00
Stippolyte
+£0.00
Sycamore
+£0.00
Taffeta
+£0.00
Warwick
+£0.00
Toughened Glass
Toughened Glass

Yes
+£40.00
No
+£0.00
Glass Styling
None
+£0.00
Square Leaded
+£0.00
Diamond Leaded
+£0.00
18mm White Georgian Bar
+£0.00
25mm White Georgian Bar
+£0.00
Choose Options

Chosen options

Ask a question
Enter your details to view your quote
Get your quote
Discount applied at checkout

Frequently Asked Questions

Premium windows are certified by U value at this current time

There are two options for the frame width – 43mm slim or 55mm standard, both have a depth of 73mm
